X-Ray Based Inspection System - AT6040B
XBIS-AT6040B is a Windows XP Based Model. This Small and Light X-Ray Based Inspection System is Designed for Quick and Effective Use Where Small and Medium Size Hand or Laptop Bags and Parcels Needs to be Screened.
- Very – Cost effective solution lowering your expenses for security staff training
- Compact mobile type conveyor-type system
- Fits through most standard size doors
- Image archiving feature with on-board
- The image review function provides an effective and quick secondary image check
General Specifications
- Tunnel Size : 600(W) x 400 (H) mm
- Conveyor Speed : 0.22
- Conveyor Max Load : 150 kg
- Wire Resolution : Typical AWG40, Guarantee AWG38
- Steel Penetration : Typical 38mm Steel, Guarantee 34mm Steel
- Film Safety : For ISO 1600
- Operating System : Windows XP
Operating Enviornment
- Storage Temperature : -40ºC to 70ºC
- Operating Temperature : 5ºC to 40ºC
- Relative Humidity : 5 to 95% non-condensing
- System Power : 220VAC (±10%) 50± 3HZ
- Power Wastage : 1.0KW (Max)
- Noise : <60DB
X-Ray Generator
- Orientation : Upward
- Tube Current : 0.2~0.7ma (adjustable)
- Anode Voltage : 160KV (adjustable)
- X-Ray Divergence Angle : 60 degree
- Generator Cooling / Working Periods : Sealed oil bath with forced air/100%
